Roofing profile
Diamond Rib+ Inverted
This product is specifically designed to be used for wall applications only.
Technical details
Effective coverage width
approx. 43/36 in
1100mm/914mm
Steel sheet thickness
26/29 gauge
Zinc coating
G90/AZ50
Total height
approx. 0.7 in
18 mm
Min. panel length
approx. 2 in
50 mm
Max. panel height
approx. 394 in
10,000 mm
Application
Wall only
Available colours
26G
*Colours may vary from the actual product.
Terra Cotta
RAL-8004
RAL-8004
Graphite Grey
RAL-7024
RAL-7024
Oxide Red
RAL-3009
RAL-3009
Black
RAL-9005
RAL-9005
Ocean Blue
RAL-5020
RAL-5020
Blue Gray
RAL-7016
RAL-7016
Burgundy
RAL-3005
RAL-3005
Chocolate Brown
RAL-8017
RAL-8017
Green
RAL-6020
RAL-6020
Moca Brown
RAL-8017
RAL-8017
Bone White
QC-28273
QC-28273
29G
*Colours may vary from the actual product.
White White
QC-28317
QC-28317
Bone White
QC-28273
QC-28273
Stone Grey
QC-28305
QC-28305
Regent Grey
QC-28730
QC-28730
Charocoal
Black
RAL-9005
RAL-9005
Coffee Brown
Dark Brown
Antique Linen
Tan
Tile Red
Burgundy
RAL-3005
RAL-3005
Dark Red
Bright Red
Slate Blue
Melchers Green
Warranty
50
YEARS
YEARS
Manufacturer's warranties
Troughed metal sheets, Roof sheets, Roof fittings, Roof and facade panels
